Asphalt storage tanks

Product introduction

Liquid asphalt heating storage equipment, a variety of models, specifications, there are vertical and horizontal two, our company according to the actual situation and needs of users on-site design and manufacture. Working principle: the heating tube bundle is located at the bottom of the equipment, the tube bundle is a parallel structure, the heating medium flow is short, the tube wall temperature is high, the heating effect is good, the temperature is uniform, the liquid asphalt at the bottom of the equipment can be heated at the same time, then the uniform heating in the tank is realized under the action of internal circulation. Vertical liquid asphalt heating storage equipment structure: heating tube bundle, tank, insulation layer, ladder, top fence, manhole, inside ladder, liquid level display, temperature display, smoke exhaust, etc. .

Product Details

Design pressure: shell (shell) atmospheric pressure MPa tube (jacket) 0.8 MPa
Design temperature: shell (shell) 200 ℃ pipe (jacket) 260 ℃
Working medium: shell (shell) asphalt pipe (jacket) thermal oil
Maximum working pressure: shell (shell) atmospheric MPa pipe (jacket) 0.7 MPa
Structure: single layer □ multi-layer (□ heat jacket □ tape winding □ wrapping)
Heat transfer area: 50 m2 Volume 150 m2 Weight ～18000kg
Specifications: Inner diameter φ5000 Wall thickness 8 mm □ Total length Total height 9760 mm

Application field

Asphalt heating and melting storage complete sets of equipment are widely used in carbon industry, road asphalt and waterproof material projects. Asphalt heating melting and storage equipment including asphalt melting equipment, asphalt melting equipment, asphalt melting equipment, asphalt melting equipment, ton bag asphalt melting equipment, asphalt melting device, asphalt tank heater, electric heating asphalt melting device, asphalt storage equipment, asphalt heating and storage equipment, asphalt tanks, asphalt tanks, asphalt tanks, asphalt tanks and other series of products. This set of equipment has a compact structure, uniform heating, fast melting speed, high efficiency, easy to control, suitable for large-scale, and at the same time can be filtered and easy to clean slag in the tank.
